Description:

1.3 inch IPS HD TFT ST7789 Drive IC 240*240 SPI Communication 3.3V Voltage SPI Interface Full Color LCD OLED Display

1.Features
SIZE 1.3inch
Display Mode Normally black IPS
Display Format Graphic 240RGB*240 Dot-matrix
Input Data SPI interface
Drive IC ST7789VW
Dimensional outline 27.78(W)*39.22 (H)*3.0+/-0.1(T)mm
Resolution 240RGB*240 Dots
LCD Active area 23.4 (W)*23.4 (H)
Dot pitch 0.0975(H) x 0.0975(V) mm
Viewing Direction All View
Operating Temperature -20～70°C
2.Pin Descriptions:
PIN No Symbol Description
1 GND Ground
2 VCC Power 3.3V
3 SCL Serial clock pin.
4 SDA Serial data input
5 RES LCM Reset pin
This pin is reset signal input. When the pin is low, initialization of the chip is
executed. Keep this pin pull high during normal operation.
6 DC Data/Command Control
7 BLK Backlight control pin

New Arrival 1.44" inch Serial 128x128 128*128 65K SPI Full Color TFT LCD Display Module Board Replace OLED

LCD PANEL : CPT
Driver IC : ST7735S
Resolution : 128*RGBX128
PIN feet :8 pin (SPI serial interface)
PIN feet spacing:2.54mm
connection mode : Row needles

3V3: 3.3V POWER INPUT
GND: Grounding power communication system
SDI: SPI DATA input
SCL : spi clock signal input
CS: spi chip select signal input
RST: reset
RS: command /data signal input selection
BLK : Backlight control signal inpuT

New Arrival 1.8" Inch Full Color 128x160 128*160 SPI Full Color TFT LCD Display Module Board Replace OLED

Resolution 128*RGB*160
PIN feet :8 pin (SPI serial interface)
PIN feet spacing:2.54mm
connection mode : Row needles

GND: Grounding power communication system
VCC: power supply
SDA: SPI DATA input
SCL : spi clock signal input
CS: spi chip select signal input
RST: reset
RS: command /data signal input selection
BLK : Backlight control signal input

1pcs IPS 0.96 inch 7P SPI HD 65K Full Color OLED Module ST7735 Drive IC 80*160 80x160

1. LCD Size: 0.96 inches

2. Dot Matrix Size: 80*160 (Display direction can be adjusted, horizontal screen and vertical screen are ok)

3. LCD Color: 65K Full Color

4. Hardware Interface: SPI interface

5. Driver IC: ST7735

6. Operating Temperature: -20 - 70

8. Working Power Supply: 3.3V

9. PIN NO: 13Pin

10. Display Area: 10.8*21.696mm

11. Size: 13.3*27.95mm

12 Viewing Direction: Full viewing angle (IPS)

1 GND
2 VCC (3.3-5 v)
3 SCL (SPI clock line)
4 SDA (SPI data cable)
5 RES
6 DC
7 BLCK

Package Include:
1 x LCD Display Module Board Replace OLED
